CP 0022 is a lightweight Pneumatic Rockdrill that provides maximum output with the lowest air consumption. The spring retainer of CP 0022 Rock Drills makes it lightweight and thus easy to operate. Even being lightweight, the performance of the drill is not compromised.
CP 0022 (8900 0020 01) comes with a combined blower and throttle lever. It makes the drill easy to operate.
Model # | CP 0022 | |
Weight | 15 kg | 33 lb |
Length | 475 mm | 18.7" |
Hole range (upto) | 40 mm | 1.57 " |
Hole depth (max.) | 2.4 metres | 7.9 ft |
Air pressure | 6.2 bar | 90 psi |
Air consumption | 22 l/s | 47 cfm |
Blows per minute | 2220 | |
Revolutions | 232 rpm | |
Piston dia | 60 mm | 2.36" |
Piston stroke | 44 mm | 1.75" |
Air inlet (Swivel) | 19 mm | ¾" |
Shank size - 8900 0020 02 | 22 x 108 mm | ⅞″ X 4¼” |
Shank size (Optional) - 8900 0020 01 | 22 x 82.5 mm | ⅞″ X 3¼” |
